Hinged insulated system SUPREME S91
Description
The system SUPREME S91 was specially designed in order to meet the high requirements of passive houses. It is ideal for heavy duty and energy efficient constructions offering a high security level. The system’s development was driven by the need for best in class performances in terms of thermal insulation, water tightness, as well as sound reduction. The system is the perfect solution for the most demanding markets.
The system SUPREME S91 was specially designed in order to meet the high requirements of passive houses. It is ideal for heavy duty and energy efficient constructions offering a high security level. The system’s development was driven by the need for best in class performances in terms of thermal insulation, water tightness, as well as sound reduction. The system is the perfect solution for the most demanding markets.
Advantages
- Maximum energy savings thanks to the Passive House energy efficiency
- High security level
- Exceptional sound insulation
- Modern design
- Ease of use and high functionality
- Exceptional quality with certified performances
- Increased static loads and functionality in case of severe weather conditions
GENERIC
Window Types
Hinged
Thermal Insulation
Yes
Exterior Shapes
Curved, Flat
TECHNIKAL CHARACTERISTICS
Frame depth
91 mm
Minimum visible aluminium face width at the central vertical column (adjoining profile)
151 mm
Glazing type
Double - Triple
Maximum glazing thickness
37 up to 81 mm
Mechanism
Euro-groove, Euro-nut
Sealing method
Perimetrical at 3 levels with EPDM & foam EPDM gaskets
Minimum threshold height
13 mm
Type of thermal insulation
Polyamides 54 mm width, ALUMIL Energy bar, Insulation foam
PERFORMANCE
Water tightness
E1650
Air permeability
4
Wind load resistance
C5/B5
Sound reduction
41 dB
CHARACTERISTICS
Types of typology
For all tilt & turn typologies
Minimum visible aluminium face height
93mm
Uf
from 0,67 W/m²K
Sash weight
up to 180 Kg
TYPOLOGIES
All available typologies
Τilt and turn with fanlight
Double tilt and turn with fanlight
Τilt and turn with fix light on top
Double tilt and turn with fixed lights sideways
Τilt and turn with fanlight
Double tilt and turn window
Double tilt and turn with light
Double tilt and turn window with fixed light
